MB 2066 GIGA X299 UD4 S/R/M2/DDR4.

Código: 238194

$285.00

Placa-mãe Intel X299 Ultra Durable com suporte para faixa de LEDs RGB Fusion, Dual M.2, SNR ALC1220 de 120 dB, LAN para jogos Intel, USB 3.1 gen 2 Tipo-A

Quantity

CPU

    Support for Intel® Core™ X series processors in the LGA2066 package
    L3 cache varies with CPU
Memory

    8 x DDR4 DIMM sockets supporting up to 128 GB of system memory.
    * Support for up to 512 GB of system memory when using Registered DIMMs.
    * Supported when using a 44-lane or 28-lane CPU (6-core or above).
    4 x DDR4 DIMM sockets supporting up to 64 GB of system memory.
    * Supported when using a 16-lane CPU (4-core).
    4 channel memory architecture.
    * Supported when using a 44-lane or 28-lane CPU (6-core or above).
    Dual channel memory architecture.
    Supported when using a 16-lane CPU (4-core).
    Support for DDR4 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
    Support for non-ECC Un-buffered DIMM memory modules
    Support for Registered DIMM 1Rx8/2Rx8/1Rx4/2Rx4 memory modules (operate in non-ECC mode)
    * R-DIMM is only supported by BIOS version F5 and earlier versions.
    Support for Extreme Memory Profile (XMP) memory modules

 Audio

    Realtek® ALC1220 codec
    High Definition Audio
    2/4/5.1/7.1-channel
    Support for S/PDIF Out

LAN

    Intel® GbE LAN chip (10/100/1000 Mbit)

Expansion Slots

    2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
    1 x PCI Express x16 slot, running at x8 (PCIEX8)
    2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
    (All of the PCI Express slots conform to PCI Express 3.0 standard.)
    * Refer to "1-6 Setting up AMD CrossFire™/NVIDIA® SLI™ Configuration," for the installation notices for the PCI Express x16 slots.

Storage Interface

    1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2Q_32G)
    1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2P_32G)
    8 x SATA 6Gb/s connectors
    Support for RAID 0, RAID 1, RAID 5, and RAID 10
    * Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

 Back Panel Connectors

    1 x PS/2 keyboard/mouse port
    2 x USB 3.1 Gen 2 Type-A ports (red)
    6 x USB 3.1 Gen 1 ports
    1 x RJ-45 port
    6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

 Form Factor

    ATX Form Factor; 30.5cm x 24.4cm
